Agie mondo 30 ram-type edm
AGIE CNC 3-AXIS (X, Y, Z) RAM-TYPE EDM MACHINE
MODEL: MONDO 30 S/N: MON 30 NR-001038 NEW:1993
(W x L x H) .......................... 30" x 25.5" x 12.6"
DIMENSIONS (W x L x H) .............. 40.5" X 28.5" X 15.5"
TABLE AREA (L x W) .................... 20-1/8" X 25-9/16"
AXIS TRAVEL (X,Y,Z) ................... 14" x 12" x 9.8"
THROAT CLEARANCE ...................... 20.4"
PLATEN TO TABLE CLEARANCE ............. 12.4" TO 22.2"
RESERVOIR CAPACITY .................... 140 GALS.
PERMISSIBLE WORKPIECE ON TABLE ........ 1,000 LBS.
PERMISSIBLE ELECTRODE WEIGHT .......... 150 LBS.
APPROX. MACHINE WEIGHT ................ 1500 KG
MACHINE TOOL DIMS. .................... 64"L-R x 90D" x 83"H
FUTURA II GENERATOR/CONTROL DIMS. ..... 21"L-R x 26"D x 72"H
AGIE FUTURA II CNC CONTROL & 50 AMP POWER SUPPLY
220 VOLTS/50-60 CYCLE/3 PH/42 KVA/FULL LOAD CURRENT 23 AMPS
10" X 18" WALKER CERMAX PERMANENT MAGNETIC CHUCK
