> Clausing-colchester 13X24 13X36 lathe op/part manual
Clausing-colchester 13X24 13X36 lathe op/part manual
13 x 24 and 13 x 36 Metal Lathe
This is a reproduction, not a photocopy, of an original Clausing/Colchester 13" x 24" and 13" x 36" Heavy Duty Geared Precision Lathes Instructions and Parts Manual, 1st edition. This manual contains operation instructions, adjustments, maintenance, lubrication, and a complete pictorial view of the parts with descriptions as shown above. Please see index below.
Headstock.............................3
Master Quick Change Feed Box..........7
Dominion Quick Change Feed Box........9
Saddle...............................11
Apron................................11
Tailstock............................12
Motor Drive..........................12
Coolant Unit.........................12
Lathe Bed............................13
Standard Equipment...................14
Extra Equipment......................14
Square Tool post.....................14
Backplates...........................14
Stationary Steady....................15
Collet Attachment....................15
Chucks...............................15
Taper Turning Attachment.............15
Main Dimensions......................16
Installation and Location............17
Cleaning.............................17
Levelling............................17
Turning Tests........................17
Lubrication..........................19
Wiring...............................19
Headstock............................21
Master Quick Change Feed Box.........23
Master Saddle........................25
Dominion Quick Change Feedbox........27
Dominion Saddle......................29
Apron................................31
Bed..................................31
Tailstock............................33
Square Tool post.....................33
Taper Turner.........................35
Stationary Steady....................35
Mechanical Clutch....................35
Electrical Equipment.................36
Chuck Spares.........................36
Service Hints........................37
