> Tektronix 613 storage display unit service & ops manual
Tektronix 613 storage display unit service & ops manual
of the INSTRUCTION MANUAL (OPERATING & SERVICE) for the
TEKTRONIX 613 STORAGE DISPLAY UNIT
The manual includes information on operation, calibration, replaceable parts, schematics and board /component locations. This scan comprises 107 pages scanned to a file size of 24MB in PDF format.
* Text with photos: 600dpi, grayscale (contrast adjusted)
* Text with Drawings: 600dpi black and white
* Schematics: 600dpi black and white
* Schematics and board overlays with color notes: 256 colors 600dpi
* Large fold out schematic pages are scanned in sections at 8.5 X 11 with a typical over lap of 1" to insure easy piecing if you print them out.
