Dayton cabinet exhaust fan 48" 208-230/460V 36764
TYPE:ASSEMBLED BELT DRIVE, PROPELLER DIAMETER 48", CFM @ 0.000-In. SP 23,174, CFM @ 0.125-In. SP 19,866, CFM @ 0.250-In. SP 15,151, CFM @ 0.375-In. SP 11,019, SONES @ 0.125-In. SP @ 5 Ft. 20, FAN RPM:445, MAXIMUM AMBIENT TEMPERATURE 104(F), MAXIMUM INLET TEMPERATURE 104 (F), VOLTAGE:208-230/460, HERTZ:60, PHASE:3, FULL LOAD AMPS:6.0-5.6/2.9, MOTOR HP:2, MAXIMUM BHP:2.30, BEARING TYPE:REGREASABLE CAST PILLOW BLOCK, MOTOR RPM:1725, MOTOR Type:3-PHASE, MOTOR ENCLOSURE:TOTALLY ENCLOSED FAN COOLED, MOTOR INSULATION CLASS F, 54 1/4"H 54 1/4"W 36 5/8"D, MOUNTING POSITION:VERTICAL, HOUSING MATERIAL:GALVANIZED STEEL, FRAME MATERIAL:GALVANIZED STEEL, PROPELLER MATERIAL:FABRICATED STEEL, NUMBER OF BLADES:5, *** THIS UNIT HAS SCRATCHES ON 7 SHUTTERS ON RIGHT SIDE***
